Deploying and Managing Applications with GKE, Helm, and Kubernetes Services & Persistent Volumes

By leveraging the power of Helm, GKE, and Kubernetes, you can easily manage and scale your applications while maintaining high availability and persistent storage. These practices are essential for building production-ready applications in the cloud.

Google Kubernetes Engine (GKE) is a powerful, managed Kubernetes service that simplifies container orchestration in the cloud. With Kubernetes, you can easily manage and scale containerized applications. One of the most efficient ways to deploy applications on GKE is using Helm, a Kubernetes package manager that streamlines deploying complex applications through reusable charts.

In this blog post, we’ll walk through how to use GKE, Helm, Kubernetes Services, and Persistent Volumes (PVCs) to deploy, expose, and persist applications. This tutorial will give you a comprehensive understanding of how to streamline your deployments and manage your infrastructure effectively.

What You Need

A Google Cloud account with GKE enabled.
Helm installed on your local machine.
kubectl configured to interact with your GKE cluster.
A Kubernetes cluster running on GKE.

Let’s dive into the steps of setting up a simple web application using Helm, with a focus on deploying a containerized app, exposing it through a Kubernetes Service, and configuring Persistent Volumes for data storage.

Step 1: Setting Up Helm

First, ensure Helm is installed on your machine. You can install Helm by following the official Helm installation guide: Helm Installation Guide.

Once Helm is installed, initialize it by adding the official Helm chart repository:

helm repo add stable https://charts.helm.sh/stable helm repo update

Step 2: Creating the Helm Chart for Your Application

Helm charts provide a convenient way to deploy complex applications. A chart typically includes several Kubernetes resource definitions, such as deployments, services, config maps, secrets, and persistent volume claims. For this example, let’s assume we want to deploy a simple FastAPI application.

Create a Helm chart for your application:

helm create fastapi-app

This command will generate a directory structure with all the necessary files for your Helm chart. You can now modify the deployment, service, and PVC configurations within this chart to suit your application’s needs.

Step 3: Defining the Deployment in Helm

A deployment in Kubernetes manages the desired state for a set of pods. For our FastAPI application, we’ll define the necessary configuration in the deployment.yaml file, which is located under the templates/ directory of the Helm chart.

Modify templates/deployment.yaml to look like the following:

apiVersion: apps/v1
kind: Deployment
metadata:
  name: {{ include "fastapi-app.name" . }}
spec:
  replicas: 1
  selector:
    matchLabels:
      app: {{ include "fastapi-app.name" . }}
  template:
    metadata:
      labels:
        app: {{ include "fastapi-app.name" . }}
    spec:
      containers:
        - name: fastapi-app
          image: "my-fastapi-app:latest"
          ports:
            - containerPort: 80

This deployment.yaml defines the FastAPI application container, including the image and port configuration. It also specifies one replica for simplicity. You can adjust this to scale your app later.

Step 4: Defining the Service in Helm

In Kubernetes, a service exposes a set of pods to external traffic. We’ll define a ClusterIP service to expose the FastAPI app within the GKE cluster.

Modify templates/service.yaml to look like this:

apiVersion: v1
kind: Service
metadata:
  name: {{ include "fastapi-app.name" . }}
spec:
  type: ClusterIP
  ports:
    - port: 80
      targetPort: 80
  selector:
    app: {{ include "fastapi-app.name" . }}

This YAML file defines a ClusterIP service for the FastAPI app. It uses the same label selector as the deployment to connect the service with the appropriate pods.

Step 5: Setting Up Persistent Storage with PersistentVolumeClaims (PVC)

In a production environment, most applications require persistent storage for data such as databases or logs. Kubernetes provides Persistent Volumes (PVs) and Persistent Volume Claims (PVCs) to manage storage. GKE supports dynamic provisioning of persistent disks, making it easy to create PVCs.

To add a PVC to your application, modify templates/pvc.yaml as follows:

apiVersion: v1
kind: PersistentVolumeClaim
metadata:
  name: my-pvc
spec:
  accessModes:
    - ReadWriteOnce
  resources:
    requests:
      storage: 1Gi
  storageClassName: standard

This PVC requests 1Gi of storage, with the default standard storage class for GKE, which dynamically provisions a Google Cloud Persistent Disk.

Step 6: Mounting the PVC in the Deployment

Now, let’s mount the PVC into the FastAPI container so it can access the persistent storage.

Modify templates/deployment.yaml to add the volume and volume mount configurations:

spec:
  containers:
    - name: fastapi-app
      image: "my-fastapi-app:latest"
      ports:
        - containerPort: 80
      volumeMounts:
        - name: my-storage
          mountPath: /path/to/storage
  volumes:
    - name: my-storage
      persistentVolumeClaim:
        claimName: my-pvc

In this configuration:

We added a volume mount to the FastAPI container to mount the PVC at /path/to/storage.
The volumes section refers to the PVC we defined earlier.

Step 7: Deploying the Application with Helm

Now that everything is configured, it’s time to deploy your application to GKE. Use the following Helm command:

helm install fastapi-app ./fastapi-app

This command will deploy your application to the GKE cluster, create the necessary services, and provision a persistent volume for your app.

Step 8: Accessing the Application

If you want to access the FastAPI app externally, you can either use a LoadBalancer service type or set up an Ingress. For example, here’s how you can change your service type to LoadBalancer:

spec:
  type: LoadBalancer

This will automatically provision an external IP in GKE, allowing you to access your application.

You can retrieve the external IP with:

kubectl get svc fastapi-app

Conclusion

In this blog post, we’ve learned how to use GKE, Helm, and Kubernetes Services & Persistent Volumes to deploy and manage a containerized application. We covered how to:
